Wide range of alternative actuators

Good resistance to oil and petroleum spirit

Actuator heads can be repositioned by 4 x 90°

Snap action with constant contact pressure up to switching point

Mechanical data
Actuating element	Roller lever
Mechanical life, minimum	30,000,000 Operations
Actuating speed, maximum	2.5 m/s
Actuating torque, minimum	0.26 Nm
Electrical data
Thermal test current	10 A
Required rated short-circuit	1,000 A
Utilisation category AC-15	230 VAC
Utilisation category AC-15	4 A
Utilisation category DC-13	24 VDC
Utilisation category DC-13	4 A
Switching element	NO contact, NC contact
Switching principle	Snap switch element
Switching frequency	5,000 /h
Switchover time, maximum	2 ms
Ambient conditions
Ambient temperature[℃]	-30...80
Protection rating	IP 67
